The Calorific Value Tester for Building Materials is mainly composed of a constant temperature bomb calorimeter and a microcomputer system. Controlled by computer software, it is a multifunctional and automated calorimetric instrument capable of processing test data. This instrument is characterized by high measurement accuracy, easy operation, reliable performance, and elegant appearance. It is primarily used to determine the heat of combustion (calorific value) of combustible materials such as coal, petroleum, chemicals, food, wood, and explosives.
Conforms to the following standards:
GB/T 14402-2007
ISO 1716-2002
Temperature Measurement Range: 0–40°C (temperature variation during each test should be ≤1°C), relative humidity ≤85%
Temperature Resolution: 0.0001°C
Test Duration:
Initial 6 minutes to stabilize water temperature
Main temperature test for 12 minutes after ignition
Total duration: 18–20 minutes (may be extended for low-calorific coal samples)
Power Consumption: <500 W
Power Supply: 220V ±10%
Dimensions: 400 mm × 575 mm × 456 mm
Measurement Accuracy: In accordance with GB/T 213-2008
Outer Bucket Capacity: 35 L
Inner Bucket Capacity: 2.3 L
Ignition Voltage: 24 V
